BENINCA MAX.CP Control Panel for 2 hydraulic bollards

The BENINCA MAX.CP Control Panel is a highly efficient and reliable solution designed specifically for managing 2 hydraulic bollards. With its advanced technology and user-friendly interface, this control panel offers seamless control and operation of the bollards, ensuring maximum security and convenience.

Equipped with state-of-the-art features, the MAX.CP Control Panel allows for easy programming and customization of various parameters, such as opening and closing times, sensitivity levels, and access control options. Its intuitive interface and clear display make it effortless to navigate and configure the settings according to specific requirements.

The control panel is built to withstand harsh environmental conditions, thanks to its durable construction and weather-resistant design. It offers reliable performance even in extreme temperatures, ensuring uninterrupted operation throughout the year.

Safety is a top priority with the BENINCA MAX.CP Control Panel. It incorporates advanced safety features, including obstacle detection and emergency stop functionality, to prevent accidents and protect both vehicles and pedestrians.

With its compact size and easy installation process, the MAX.CP Control Panel is suitable for various applications, such as residential complexes, commercial buildings, and parking facilities. It seamlessly integrates with the hydraulic bollards, providing a comprehensive and efficient access control solution.

Overall, the BENINCA MAX.CP Control Panel is a top-of-the-line product that combines cutting-edge technology, user-friendly operation, and robust safety features. It offers a reliable and convenient solution for managing 2 hydraulic bollards, ensuring optimal security and ease of use.

Additional Information

RISE MAX.CP Control Panel for 2 hydraulic bollards

• 230 Vac 50/60 Hz power supply
• Control panel for 1 or 2 hydraulic bollards
• Integrated 433.92 MHz 64-code receiver with 3 encoding systems (Advanced Rolling Code, Rolling Code, Fixed Code)
• Removable terminal boards
• Parameter and operation logic regulations through integrated LCD display
• Automatic, semi-automatic and deadman’s logic
• Programming access password
• Equipped with step-by-step command inputs separate for each bollard and centralised command inputs ALL UP and ALL DOWN for the raising and the lowering of both bollards
• Separate limit switch inputs for each motor
• Control inputs for loop detectors and protection devices (GL.PRES)
• 2 outputs configurable as bollard status indicator or command of the optional board CP.BL
• Designed for the connection of the optional board CP.BL to manage signal lights and the warning buzzer GL.BUZZ
• Protection level IP54
