Manufacturer: CAME

CAME Electro mechanical underground operator single kit Frog-S 230v for up to 3.5m

CAME Electro mechanical underground operator single kit Frog-S 230v for up to 3.5m


Regular price £640.94
Regular price Sale price £640.94
Sale Sold out
Tax included.

Single gate kit. 230v. Max 3500mm. 800kg. Per gate.


Complete kit for a single residential or apartment block swing gate up to a maximum of 3.5m in width or 800kg in weight for each leaf

Ultimate Choice in Aesthetical Appearance

This underground equipment is specifically designed so that the motor is concealed in a load-bearing foundation box beneath the pivot point of your hinged swing gates Giving you the very best in aesthetics while further reducing hazards by removing more trapping points above ground level.

Manual Release from outside

Manual release from outside the property in the event of a power failure or fault. Particularly useful when the gate is the only means of access to the property.

Integrated Open & Close Limits

This equipment features adjustable open and close limits. This allows you to set the limits of the gate of travel without the need for a physical stop in the ground. This feature has some limitations and may not function correctly on wider gates. If your gates are over 1.8m in width it is advisable to talk to us before ordering if this feature is critical to your installation.

The new RGSM range exploits GSM networks and gives, end-users and installers, total control of automated systems, at all times. This particular module also provides smart operation of all types of automation: thanks to the RGSM, you can now connect and remotely manage all automated devices in the CAME range.

Frog-S 230v Electro mechanical underground operator single kit up to 3.5m leaf

kit includes,

  • 1x Frog-A underground operators
  • 1x Frog-CF foundation case
  • 1x A4364 release mechanism
  • 1x DIR-10 pair of photocells
  • 1x ZA3N control panel
  • 2x TOP-432NA remote transmitters
  • 1x TOP-A433N antenna
  • 1x AF43S radio card
